TIKET PRINTER
Tiket Printer
TIKET PRINTER e-print
Embedded adalah bagian dari tiket printer e-print yang menjalin komunikasi data dari dispenser dan komputer master (optional). Perangkat modul embedded adalah:
1. Tombol Keypad Heavy duty industrial grade
2. Layar LCD grafik
3. Reader Mifare Smart Card (optional)
4. Power Supply / Adaptor (mini printer dan modul embedded)
GAS STATION PRODUCT
Automatic Tank Gauging ATG Console
Specification :
Power : AC220V 50/60Hz
Display size : 10′ colorful LCD
Display resolution : 800×600
Dimension : 140x300x230
Fitur :
Secara otomatis memantau level minyak, suhu dan air tangkiSecara otomatis menghitungvolume minyak, air dan tangki kosongmenggunakan layar berwarna dan touchscreenSupport progam ITL Enabler(FCC)
ATG e Flow
Benefit
- Kemudahan dan ketepatan dalam mendapatkan informasi stok, pengisian, event dan penyusutan tangki
- Berguna untuk mengurangi resiko pencurian BBM di dalam tangki pendam atau penerimaan BBM dari mobil tangki
- Memudahkan pengawasn dan pengelolaan SPBU, juga dapat di akses lewat smartphone via SMS dan Telegram
- Membantu manajemen SPBU dalam menganalisa stok BBM dan penyusutuan
- Membantu pengaturan penebusan BBM
Self Service
Benefit :
1. Transaksi pembelian BBM dapat di lakukan tanpa operator, mudah dan aman.
2. Dilengkapi dengan Bill Acceptor (penerima uang tunia)
3. Menerima pecahan uang tunai mulai Rp. 2000 sampai Rp 100.000
4. Cetak nota dilengkapi barcode atau QRcode
Web Fuel
Benefit
- Real TIme : Menampilkan data dan status pompa secara real time dan di lengkapi indikator gambar
- Akurat dan Lengkap : Laporan penjualan BBM di dapatkan hingga LABA Kotor
- Report : Laporan penjualan real time, shift, harian, dan bebas (jangka waktu yang di inginkan)
- Terpadu : Perubahan setting harga dan jenis BBM
- Member’s Card : Mencetak data pelanggan secara otomatis dengan teknologi Smart Card
- Telegram Messenger Report : Mengetahui laporan Penjualan Via Smartphone
- Remote Sofrware : Mengakses / Mengoleksi data dan informasi penjualan dari tempat yang jauh
- Secure : Bisa mendeteksi totaliser yang di mundurkan
- Grafik da Trend : Membantu manajemen SPBU dalam menganalisa hasil penjualan
- Efisiensi dan Efektifitas : Manajemen di SPBU dapat di tingkatkan
Tiket Printer
TIKET PRINTER e-print
Embedded adalah bagian dari tiket printer e-print yang menjalin komunikasi data dari dispenser dan komputer master (optional). Perangkat modul embedded adalah:
1. Tombol Keypad Heavy duty industrial grade
2. Layar LCD grafik
3. Reader Mifare Smart Card (optional)
4. Power Supply / Adaptor (mini printer dan modul embedded)
ARCHMETER PRODUCT
RFID PRODUCT
Mifare 13.56MHz RFID ISO14443A
- Reading distance: up to 50mm
- Frequency: 13.56 MHz
- Read Mifare UltraLight and MF1 Standard cards
- Three -In -One interface, with Wiegand, MSR ABA TK2 and RS232 interfaces
- Fast data transfer
- Weather resistant
- High data integrity
- User convenience
- Easy to install
- Available to install on metal surface
Proximity EM RFID Reader \125KHz EM Card Reader
- Low cost
- Long read range
- Small outline
- Wide voltage range
- Potted for environmental protection
- Externally programmable interface
- Weather resistant
AUTOMATIC TANK GAUGE PRODUCT
Automatic Tank Gauging ATG Console
Specification :
Power : AC220V 50/60Hz
Display size : 10′ colorful LCD
Display resolution : 800×600
Dimension : 140x300x230
Fitur :
Secara otomatis memantau level minyak, suhu dan air tangkiSecara otomatis menghitungvolume minyak, air dan tangki kosongmenggunakan layar berwarna dan touchscreenSupport progam ITL Enabler(FCC)
Auto Tank Gauge – Smart Magnetostrictive Probe
Technical parameters
- Precision ±0.5mm
- Repeatability ±0.2mm
- Resolution of product level: 0.01mm
- Resolution of water level: 0.01mm
- Resolution oftemperature: 0.0625℃
- Temperature range: -40℃~60℃
- Temperature points measured: 5
- Maximumcommunication distance: 500m
- Communication port : RS-485
- Mark of explosion proof : ExiaⅡAT5 Ga
- Protection level : IP67
- Measured medium: Gasoline, kerosene, diesel, light oil
- Maximum measure length : 4500m
- Oil float kits : 2” Water float kits : 2”
Features:
- Latest magnetostrictive technology and digital electronic technology
- High quality 316 stainless steel ensures longer lifetime for the probe, even in harshest environment.
- Five precise sensors ensure the accurate temperature measurement of oil product.
- Easy installation without maintenance.
- Used for gasoline, diesel, kerosene and other light oil.
- Available length is from 1m to 4m.
CZ-GR Explosion-proof intelligent magnetic level probe
CZ-GR The explosion-proof intelligent magnetic liquid level probe is a high-precision displacement measurement sensor developed and produced by the principle of magnetostriction. It has the advantages of high measurement accuracy, stability and reliability, long life, compact structure, and strong environmental adaptability. It does not require installation on the top of the tank Can clearing is safe, convenient and fast.
This product is designed and certified in accordance with the requirements of GB3836-2000 “Explosion-proof Electrical Equipment for Explosive Environments”, explosion-proof mark: ExiaIICT6, explosion-proof certificate: CE092036. Electromagnetic compatibility design, with anti-static, anti-surge and anti-interference design.
| Parameter / model | CZ-GR probe |
| Measuring range | 0.3~25m |
| Measuring accuracy of liquid level and interface | ±1~1.5mm |
| Resolution | 0.1mm |
| Number of temperature measurement points | 5 |
| Temperature detection range | -40~55°C 0.0625°C |
| Medium density range | 0.4~2.5g/cm3 |
| Work pressure | -0.05~10MPa |
| Protection level/explosion-proof mark | IP67/ExiaIICT6 |
| Operating Voltage | DC12~24V |
| Working current | Less than 50mA |
| Communication standard | RS485 |
| Material of probe float | 316L |
:
